Series N22 N32 Medium Heavy-Duty Casters – 6 inch Diameter

Description

FOB: Our Georgia Warehouse

When strength, durability, and American-made craftsmanship matter, turn to the Series N22/N32 Medium Heavy Duty 6″ Casters from Fairbanks Company—available now from Material Flow. Designed with a one-piece swivel horn (no welds) for maximum integrity, these casters dramatically reduce failure risk and extend service life. The 3/4″ orbit-formed kingpin and hardened steel components support high-load applications, while a specialized nylon grease seal ring keeps out debris and locks in lubrication—even in temperatures from –20°F to 230°F. Finished in your choice of rugged grey epoxy or corrosion-resistant zinc plating, and fully compliant with ASME B56.11.1 standards, these casters are the go-to choice for industrial operations demanding high performance.

• Brand: Fairbanks Company

• Series: N22 / N32

• Made in: U.S.A

• Wheel Diameter: 6 inches

• Overall Height: 7-1/4″

• Swivel Lead: 1-3/4″

• Top Plate Dimensions: 4″ x 4-1/2″

• Bolt Hole Size: 3/8″

• Top Plate Style: Slotted bolt holes

• Kingpin: 3/4″, orbit-formed, unitized design

• Horn Construction: One-piece swivel, no welds

• Finish Options: Grey epoxy powder coat or zinc-plated

• Seal Ring Temp. Range: –20°F to 230°F

• Compliance: Meets ASME B56.11.1 standards

• Note: Steel surcharge may apply
