Reelcraft HD76070 OLP 3/8 in. x 70 ft. Heavy Duty Mobile Base Hose Reel – Reel & Hose

Description

The Reelcraft Series HD70000 hose reels incorporate a heavy-duty base design, all-steel construction and a baked-on powder coat finish to produce a rugged, corrosion-resistant product.

Features

• Spool is constructed from a rugged engineered plastic
• Individually powder coated steel components offer maximum protection from premature corrosion
• The steel guide arm and base are stamped with ribs and gussets to ensure maximum strength and lightest possible weight
• Widened ratchet and latch pawl design greatly reduces wear and increases service life
• Low-pressure 1/2 in. x 50 ft. PVC hose included; hose is for air or water service only
• The industrial-grade drive spring completely containerized and permanently sealed
• Inlet hose is plumbed into the base to eliminate the risk of undue stress on the swivel
• Guide arm adjusts to seven positions
• Made in the USA

Fluid Path Materials

• Internal Fluid Path: Steel
• Swivel Assembly: Steel
• Swivel Seal: Nitrile Rubber

Specifications

• Weight: 49 lbs
• Series: HD70000
• Hose ID: 3/8 in.
• Hose OD: 0.600 in.
• Hose Length: 70 ft.
• Pressure: 300 psi
• Hose End: 1/4 in. NPT(M)
• Inlet: 1/2 in. NPT(F)
• Reel Outlet: 1/2 in. NPT(F)
• Hose Included: Yes
• Max Temperature: 150 °F
• UPC: 699567017806

Downloads

Product Manual
