M6-1.0 X 65mm DIN 84 / ISO 1207, Metric, Machine Screws, Cheese Head Slot Drive, Full Thread, A4 Stainless Steel

Description

• Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
• A4 stainless steel is functionally equivalent to 316 grade and is also known as “marine grade”.
• Stainless steel significantly improves resistance to tarnishing or corrosion.

• Diameter (Nominal): M6
• Thread Pitch: 1.0
• Diameter (Dimension): 6mm
• Length (Nominal): 65mm
• Thread Length: 65mm
• Head Diameter: 10mm
• Head Diameter (Minimum): 9.78mm
• Head Diameter (Maximum): 10mm
• Head Height, Overall: 3.9mm
• Head Height, Overall (Minimum): 3.6mm
• Head Height, Overall (Maximum): 3.9mm

• Product Class: Externally Threaded Fasteners
• Order: Machine Thread Fasteners
• Category: Machine Screws
• System of Measurement: Metric
• Brand: Aspen Fasteners®
• Head Style: Cheese Head
• Drive Style: Slotted Drive
• Thread Length: Full Thread
• Thread Direction: Right-Hand Thread
• Material: Stainless Steel
• Material Grade: A4 Stainless Steel
• Coating: Uncoated
• Standards and Specifications: DIN 84 / ISO 1207
