M5 X 120mm Particle Board Screws, Metric, Flat 6Lobe Torx(r) Drive, Nibs Under Head, Type 17 Point, Part Thread, 410 Stainless Steel, Art. 9147

Description

• Particle board screws are designed for use in dense woods such as particle boards or chipboards.
• A 6-lobe recess is also known as a hexalobular internal drive.
• Flat countersunk head screws sit flush with the surface of the material they are inserted into.
• Type 17 point screws feature a long sharp point that is fluted in order to capture chips.
• Stainless steel significantly improves resistance to tarnishing or corrosion.

DIMENSIONAL ATTRIBUTES

• Diameter (Nominal): M5
• Diameter (Dimension): 5mm
• Length (Nominal): 120mm
• Thread Length (Nominal): 70mm
• Drive Recess Size: T25
• Head Diameter: 10mm
• Head Height, Overall: 3mm

PRODUCT ATTRIBUTES

• Category: Particle Board Screws
• System of Measurement: Metric
• Brand: Aspen Fasteners
• Form and Design: Reinforced Head
• Head Style: Flat Countersunk Head
• Head Style Detail: Nibs Under Head
• Drive Style: 6Lobe Drive
• Drive Detail: Torx® Generic Alternative
• Thread Length: Part Thread
• Thread Direction: Right-Hand Thread
• Point: Type 17 Point
• Material: Stainless Steel
• Material Grade: 410 Stainless Steel
• Coating: Uncoated
• Origin: Origin Undefined
• Standards and Specifications: Art. 9147
