M5 X 10mm DIN 661 / ISO 1051, Metric, Solid Rivets, Flat Countersunk Head, Steel

Sale!
M5 X 10mm DIN 661 / ISO 1051, Metric, Solid Rivets, Flat Countersunk Head, Steel

M5 X 10mm DIN 661 / ISO 1051, Metric, Solid Rivets, Flat Countersunk Head, Steel

Original price was: $51.18.Current price is: $29.00.

77 in stock

SKU: GABTO774853 Category:

Description

  • Solid rivets are simply a shaft and head designed to be deformed with a hammer or rivet gun.
  • Flat countersunk head screws sit flush with the surface of the material they are inserted into.

DIMENSIONAL ATTRIBUTES

  • Diameter (Nominal): M5
  • Diameter (Dimension): 5mm
  • Diameter (Minimum): 4.82mm
  • Diameter (Maximum): 5.15mm
  • Length (Nominal): 10mm
  • Unthreaded Shank Length: 7.5mm
  • Head Diameter: 8.8mm
  • Head Diameter (Minimum): 8.22mm
  • Head Diameter (Maximum): 8.8mm
  • Head Height, Overall: 2.5mm

PRODUCT ATTRIBUTES

  • Category: Solid Rivets
  • System of Measurement: Metric
  • Brand: Aspen Fasteners®
  • Head Style: Flat Countersunk Head
  • Head Style Detail: 75 Degree Countersink
  • Material: Steel
  • Material Grade: Low Carbon Steel
  • Coating: Uncoated
  • Standards and Specifications: DIN 661 / ISO 1051

Product UPC Code:
