M4.5 X 20mm Particle Board Screws, Metric, Pan 6Lobe Torx(r) Drive, Full Thread, A4 Stainless Steel, Art. 9045

Description

• Particle board screws are designed for use in dense woods such as particle boards or chipboards.
• A 6-lobe recess is also known as a hexalobular internal drive.
• Pan head screws are also known as raised cheese head screws.
• A4 stainless steel is functionally equivalent to 316 grade and is also known as “marine grade”.
• Stainless steel significantly improves resistance to tarnishing or corrosion.

DIMENSIONAL ATTRIBUTES

• Diameter (Nominal): M4.5
• Diameter (Dimension): 4.5mm
• Length (Nominal): 20mm
• Thread Length (Nominal): 20mm
• Drive Size: T20
• Head Diameter: 9mm
• Head Height, Overall: 3.1mm

PRODUCT ATTRIBUTES

• Category: Particle Board Screws
• System of Measurement: Metric
• Brand: Aspen Fasteners®
• Form and Design: Reinforced Head
• Head Style: Pan Head
• Drive Style: 6Lobe Drive
• Drive Detail: Torx® Generic Alternative
• Thread Length: Full Thread
• Thread Direction: Right-Hand Thread
• Point: Standard Point
• Material: Stainless Steel
• Material Grade: A4 Stainless Steel
• Coating: Uncoated
• Standards and Specifications: Art. 9045
