M3 X 28mm DIN 7 Type A, Metric, Solid Dowel Pins, A1 Stainless Steel

Sale!
M3 X 28mm DIN 7 Type A, Metric, Solid Dowel Pins, A1 Stainless Steel

M3 X 28mm DIN 7 Type A, Metric, Solid Dowel Pins, A1 Stainless Steel

Original price was: $41.78.Current price is: $22.72.

46 in stock

SKU: GABTO774858 Category:

Description

  • Using receiving holes, dowel pins use friction to hold parts of an assembly together.
  • Can be used as pivot pins, hinges, or locating pins.
  • Stainless steel significantly improves resistance to tarnishing or corrosion.
  • Diameter (Nominal): M3
  • Diameter (Dimension): 3mm
  • Diameter (Minimum): 3.002mm
  • Diameter (Maximum): 3.008mm
  • Length (Nominal): 28mm
  • Ball End Height: 0.45mm
  • Product Class: Pins and Wireforms
  • Order: Dowel Pins
  • Category: Solid Dowel Pins
  • System of Measurement: Metric
  • Brand: Aspen Fasteners®
  • Form and Design: Rounded Ends
  • Tolerance: Tolerance m6
  • Material: Stainless Steel
  • Material Grade: A1 Stainless Steel
  • Material Processes: Unhardened
  • Coating: Uncoated
  • Standards and Specifications: DIN 7 Type A

Product UPC Code:
698435194434
