M3 X 25mm DIN 660 / ISO 1051, Metric, Solid Rivets, Round Head, Steel

Sale!
M3 X 25mm DIN 660 / ISO 1051, Metric, Solid Rivets, Round Head, Steel

M3 X 25mm DIN 660 / ISO 1051, Metric, Solid Rivets, Round Head, Steel

Original price was: $52.67.Current price is: $41.81.

22 in stock

SKU: GABTO775126 Category:

Description

  • Solid rivets are simply a shaft and head designed to be deformed with a hammer or rivet gun.

DIMENSIONAL ATTRIBUTES

  • Diameter (Nominal): M3
  • Diameter (Dimension): 3mm
  • Diameter (Minimum): 2.87mm
  • Diameter (Maximum): 3.1mm
  • Length (Nominal): 25mm
  • Unthreaded Shank Length: 25mm
  • Head Diameter: 5.2mm
  • Head Diameter (Minimum): 4.9mm
  • Head Diameter (Maximum): 5.2mm
  • Head Height, Overall: 1.8mm
  • Head Height, Overall (Minimum): 1.675mm
  • Head Height, Overall (Maximum): 1.925mm

PRODUCT ATTRIBUTES

  • Category: Solid Rivets
  • System of Measurement: Metric
  • Brand: Aspen Fasteners®
  • Head Style: Round Head
  • Material: Steel
  • Material Grade: Low Carbon Steel
  • Coating: Uncoated
  • Standards and Specifications: DIN 660 / ISO 1051

Product UPC Code:
