M24-3.0 DIN 80701, Metric, Butterfly Toggle Nuts, A4 Stainless Steel

Sale!
M24-3.0 DIN 80701, Metric, Butterfly Toggle Nuts, A4 Stainless Steel

M24-3.0 DIN 80701, Metric, Butterfly Toggle Nuts, A4 Stainless Steel

Original price was: $75.58.Current price is: $44.13.

26 in stock

SKU: GABTO774864 Category:

Description

  • Functionally similar to a wing nut, a butterfly toggle nut is often used in ship building.
  • A4 stainless steel is functionally equivalent to 316 grade and is also known as “marine grade”.
  • Stainless steel significantly improves resistance to tarnishing or corrosion.
  • Diameter (Nominal): M24
  • Thread Pitch: 3.0
  • Diameter (Dimension): 24mm
  • Thread Length: 32mm
  • Wing Spread: 280mm
  • Base Height: 32mm
  • Base Width: 50mm
  • Thickness (Nominal): 20mm
  • Height (Basic): 90mm
  • Product Class: Internally Threaded Fasteners
  • Order: Nuts
  • Category: Toggle Nuts (Butterfly)
  • System of Measurement: Metric
  • Brand: Aspen Fasteners®
  • Drive Style: Thumb Drive
  • Thread Length: Full Thread
  • Thread Direction: Right-Hand Thread
  • Material: Stainless Steel
  • Material Grade: A4 Stainless Steel
  • Coating: Uncoated
  • Standards and Specifications: DIN 80701

Product UPC Code:
692559697598
