M1.6-0.35 X 5mm ISO 14583, Metric, Machine Screws, Pan 6Lobe Torx(r) Drive, A4 Stainless Steel

Description

• ISO 14583 formerly referred to the DIN 7985 specification.
• Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
• A 6-lobe recess is also known as a hexalobular internal drive.
• Pan head screws are also known as raised cheese head screws.
• A4 stainless steel is functionally equivalent to 316 grade and is also known as “marine grade”.
• Stainless steel significantly improves resistance to tarnishing or corrosion.

• Diameter (Nominal): M1.6
• Thread Pitch: 0.35
• Diameter (Dimension): 1.6mm
• Length (Nominal): 5mm
• Thread Length: 5mm
• Recess Size: T5
• Head Diameter: 3.2mm
• Head Diameter (Minimum): 2.9mm
• Head Diameter (Maximum): 3.2mm
• Head Height, Overall: 1.3mm
• Head Height, Overall (Minimum): 1.16mm
• Head Height, Overall (Maximum): 1.3mm

• Product Class: Externally Threaded Fasteners
• Order: Machine Thread Fasteners
• Category: Machine Screws
• System of Measurement: Metric
• Brand: Aspen Fasteners®
• Head Style: Pan Head
• Drive Style: 6Lobe Drive
• Drive Detail: Torx® Generic Alternative
• Thread Length: Full Thread
• Thread Direction: Right-Hand Thread
• Material: Stainless Steel
• Material Grade: A4 Stainless Steel
• Coating: Uncoated
• Standards and Specifications: ISO 14583
