Kuriyama Alfagomma T505OG 4 in. Acid & Chemical Hose, 240 PSI – Hose Only

Description

Kuriyama Alfagomma T505OG is a Suction and transfer service hose designed for a variety of chemicals and solvents. This hose is able to handle 90% of existing chemicals.

Features

• Suction and transfer service for a variety of chemicals and solvents.
• Will handle 90% of existing chemicals.
• Contatnt Pressure of 16 Bar (240 PSI)
• Recommended operating temperature of -22°F to 176°F (-30°C to 80°C)

Specifications

• Brand: Kuriyama
• Part Number: T505OG400X100
• Weight: 2.50 lbs/f
• Series: T505OG
• ID Size: 4 in.
• OD Size: 4.65 in.
• Length: Per Ft.
• Full Reel Length: 100 ft
• Service Temperature Range: -22°F to 176°F (-30°C to 80°C)
• Vacuum Rating: 24 inHg
• Tube Material: Transparent XLPE (cross-linked polyethylene)
• Cover Material : Green EPDM – abrasion and ozone resistant
• Reinforcement Material: High tensile textile cords with flexible steel helix wire
• Ends: Hose Only – No Ends
• Working Pressure: 240 PSI
• Compatible Fluids: Water, Air, Chemicals (Harsh), Chemicals (Mild)
• Min Bend Radius: 26 1/2 in
