Campbell Fittings RHM-050P-304ZP Horizontal Mount Rod – 1/2 in. Pipe

Description

Campbell Fittings RHM-050P-304ZP Horizontal Mount Rod – 1/2 in. Pipe

Designed for cleanrooms, biotech, pharmaceutical, food processing, and more, this mount ensures low flow and low-pressure systems with moderate vibration remain secure. Made from durable 304 and 316 stainless steel, it features FDA-grade silicone rubber inserts. Ideal for applications such as WFI, SIP, CIP, process, utility, and instrument lines, it offers reliable performance in various critical environments.

Features

• Insulation Envelope (IE): Reduced OD allows the hanger to be encased under insulation
• ZERO PUDDLE Silicone Inserts: Raised geometry facilitates drainage, improving uptime in vertical or riser lines
• Threaded Section: Extended threading increases elevation adjustment for slope alignment
• No Exposed Threads: Hardware plates are polished and free from exposed threads or openings

Specifications

• Part Number: RHM-050P-304ZP
• Pipe Size: 1/2 in.
• Material: 304 and 316 Stainless Steel
• Temperature Range: -40°F to 320°F (intermittent), -20°F to 302°F (continuous)
