The Balcrank mechanical-metered control valves have been specifically designed to measure and dispense fluids using improved technology and innovation. Balcrank manufactures a full range of rotary-piston mechanical meters, graduated in quarts, gallons or liters to cover the needs of production lines, filling engines, gear boxes and transmissions; or when dispensing lubricants in fleet service shops, off-road vehicles, mining, or marine equipment maintenance facilities.
Features
1-piece molded pointer knob is resistant to impacts
No calibration required; precision machined metering chamber assures repeatable
accuracy
Viscosity and temperature change do not affect the accuracy
33% improved performance over competitive mechanical meters
5-digit totalizer; keeps lifetime record of volume dispensed
Easy access filter in swivel at meter inlet swivel protective cover
Unique 1/4 turn manual tip; fast, simple
Flanged coupling; prevents leaks commonly found in competitive meters
Ergonomic comfort handle
Specifications
Units of measure: Gallons and Liters (in 0.01 increments)
Accuracy: +/- 0.65%
Flow Rate: 0.26 – 8 gal/min (1 – 30 l/min)
Maximum pressure: 1,450 psi (100 bar)
Swivel Inlet: 1/2 in. NPT(F) Swivel
Dispense Nozzle OD: Auto = 0.605 in. Manual 1/4 turn for OIL = 0.705 in. Manual 1/4 turn for ATF= 0.315 in. Verify ID of ATF fill port for compatibility
Operating Temperature: 14º F to 140º F (-10º C – 60 ºC)
Weight: 3.75 lb (1.7 kg)
Compatible Fluids: Oil, transmission fluid, hydraulic fluid, and anti-freeze
