#2-56 X 5/16″ Machine Screws, Binding Undercut Head, Slotted Drive, Full Thread, Stainless Steel

Description

• Machine screws are designed for applications with a pre-tapped hole or mated to a threaded nut.
• 18-8 stainless steel is functionally interchangeable with type 304 stainless steel.
• Stainless steel significantly improves resistance to tarnishing or corrosion.

DIMENSIONAL ATTRIBUTES

• Diameter (Nominal): 2
• Thread Pitch: 56
• Diameter (Dimension): 0.086″
• Length (Nominal): 5/16″
• Thread Length (Nominal): 0.313″
• Head Diameter (Minimum): 0.171″
• Head Diameter (Maximum): 0.181″
• Head Height, Overall (Minimum): 0.043″
• Head Height, Overall (Maximum): 0.050″
• Slot Depth (Minimum): 0.020″
• Slot Depth (Maximum): 0.030″
• Slot Width (Minimum): 0.023″
• Slot Width (Maximum): 0.031″

PRODUCT ATTRIBUTES

• Category: Machine Screws
• System of Measurement: Inch
• Brand: Aspen Fasteners
• Head Style: Binding Undercut Head
• Drive Style: Slotted Drive
• Thread Length: Full Thread
• Thread Direction: Right-Hand Thread
• Material: Stainless Steel
• Material Grade: 18-8 Stainless Steel
• Coating: Uncoated
• Origin: Origin Undefined
• Standards and Specifications: ASME B18.6.3 and SAE J82
