#10 X 2-1/2″ Self-Tapping Sheet Metal Screws, Type “A”, Flat Phillips Drive, Stainless Steel

Description

• Also known as self-tapping screws, these are mostly used in thin gauge sheet metal applications.
• Type “A” sheet metal tapping screws feature a sharp point and coarse threading.
• Flat countersunk head screws sit flush with the surface of the material they are inserted into.
• 18-8 stainless steel is functionally interchangeable with type 304 stainless steel.
• Stainless steel significantly improves resistance to tarnishing or corrosion.

DIMENSIONAL ATTRIBUTES

• Diameter (Nominal): 10
• Thread Pitch: 12
• Diameter (Dimension): 0.19″
• Major Diameter: 0.194″
• Minor Diameter: 0.126″
• Length (Nominal): 2-1/2″
• Thread Length (Nominal): 2.384″
• Drive Recess Size: 2
• Head Diameter: 0.362″
• Head Height, Overall: 0.116″

PRODUCT ATTRIBUTES

• Category: Self-Tapping Sheet Metal Screws
• System of Measurement: Inch
• Brand: Aspen Fasteners
• Form and Design: Type “A”
• Head Style: Flat Countersunk Head
• Head Style Detail: 82 Degree Countersink
• Drive Style: Cruciform Recess Drive
• Drive Detail: Phillips Type H
• Thread Length: Full Thread
• Thread Direction: Right-Hand Thread
• Material: Stainless Steel
• Material Grade: 18-8 Stainless Steel
• Coating: Uncoated
• Origin: Origin Undefined
• Standards and Specifications: ASME B18.6.3
